Let us consider the problem for $n = 3$. One can show that for the optimal solution, we have WLOG $x_1 = x_2 < x_3$ (exercise) when $x$ maximises $x_1^3 + x_2^3 + x_3^2$. As mentioned in David G. Stork's answer, the domain over which you're maximising in this case is a circle, so it's trivial to solve the problem using 1D maximisation techniques.
Now for the $n$-dimensional case. WLOG, suppose $x_1 \leq x_2 \leq x_3$ with at least 2 of these values distinct. Then define $k = \frac{x_1 + x_2 + x_3}{3}$. Then let $j^2 = (x_1 - k)^2 + (x_2 - k)^2 + (x_3 - k)^2$, $j$ positive. Then we see that picking $y_i = \frac{x_i - k}{j}$, the $y_i$ must maximise $y_1^3 + y_2^3 + y_3^2$ under the constraints that $y_1 + y_2 + y_3 = 0$ and $y_1^2 + y_2^3 + y_3^2 = 1$. This shows that it must be the case that $x_1 = x_2 < x_3$.
So this means that $n$ can only take on two different values, $a$ and $b$, since if we took on three different values, we would have WLOG $x_1 < x_2 < x_3$. And we must have at least two different values, for if we only had one value, it would need to be zero, but that contradicts $\sum x_i^2 = 1$.
WLOG, suppose $a < b$. We can only have a single occurence of $b$ in $x$. For if we had 2 or more, then WLOG take $x_1 = a$ and $x_2 = x_3 = b$. Then $x_1 < x_2 = x_3$. Then $x_1 = x_2$; contradiction.
So we must have $n - 1$ occurences of $a$ and $n$ occurences of $b$. This gives us the following: $(n - 1)a + b = 0$. Then $b = -(n - 1) a$. Then $(n - 1) a^2 + b^2 = (n - 1)a^2 + (-(n - 1)a)^2 = n(n - 1) a^2 = 1$. Then $a = \pm \sqrt{\frac{1}{n(n - 1)}}$, and $b = \mp \sqrt{\frac{n - 1}{n}}$. Clearly, we must have $a$ negative and $b$ positive. This gives us our maximising quantity of $(n - 1) (-\sqrt{\frac{1}{n(n - 1)}})^3 + (\sqrt{\frac{n - 1}{n}})^3$.
